LD/LLDPE HIGH SPEED BLOWN FILM LINE SINGLE HEAD TYPE

LD/LLDPE HIGH SPEED BLOWN FILM LINE SINGLE HEAD TYPE

● LD / LLDPE High Speed Blown Film Line, High capacity, High efficiency for PE shrinking film, Agriculture film & Industrial film with jombo gusseting device.

LD/LLDPE HIGH SPEED BLOWN FILM LINE SINGLE HEAD TYPE 　 BACK
  • Specification
  • Video
  • Photograph
  • Device
MODEL   KS-FLL55 KS-FLL65 KS-FLL75 KS-FLL85 KS-FLL100 KS-FLL120 KS-FLL150
FEATURE MATERIAL TO BE USED   LOW DENSITY ROLYETHYLENE RESIN
MAX. FILM WIDTH   950 mm   1400 mm   1600 mm   2000 mm   2700 mm   3200 mm   5000 mm
THICKNESS OF FILM   0.01~0.25 m/m
MAX. EXTRUSION OUTPUT   120 kg/hr   160 kg/hr   220 kg/hr   280 kg/hr   350 kg/hr   430 kg/hr   850 kg/hr
EXTRUDER SCREW DIA.   55 mm   65 mm   75 mm   85 mm   100 mm   120 mm   150 mm
SCREW L/D   30:1   30:1   30:1   30:1   30:1    30:1   30:1
SCREW MATERIAL   SACM-645 STEEL WITH HARD WITH NITROGEN TREATMENT
BARREL MATERIAL   SACM-645 STEEL WITH HARD WITH NITROGEN TREATMENT
BARREL COOLING   1/2 HP x 3   1/2 HP x 3   1/2 HP x 4   1/2 HP x 4   1/2 HP x 4   1/2 HP x 6   1/2 HP x 7
DRIVING MOTOR + INVERTER CONTROLLER   40 HP   50 HP   75 HP   100 HP   150 HP   175 HP   300 HP
DIE HEATER CAPACITY   23 KW   32 KW   42 KW   55 KW   70 KW   80 KW   100 KW
DIE (mm)   ø250   ø300   ø400   ø500   ø650   ø800   ø1150
CONTROL PANEL TYPE   INDEPENDENCE TYPE SWITCH BOARD (BOX)
TEMPERATURE CONTROL   7 ZONES   7 ZONES   8 ZONES   8 ZONES   9 ZONES   11 ZONES   12 ZONES
COOLING EQUIP TYPE   AIR COOLING SYSTEM
AIR BLOWER + INVERTER CONTROLLER   5 HP   7 1/2 HP   10 HP   10 HP   15 HP   15 HP   20 HP
TAKE-UP UNIT TYPE   FIXED TYPE
PINCH ROLLNG (mm)   165 x 1000L   165 x 1500L   165 x 1700L   215 x 2100L   270 x 2800L   270 x 3300L   300 x 4200L
TAKE-UP MOTOR + INVERTER CONTROLLER   1 HP   2 HP   3 HP   3 HP   5 HP   5 HP   7 1/2 HP
TAKE-UP SPEED (m/min)   5~50   5~50   5~50   5~50   5~50   5~50   5~50
COLLAPSING FRAME & BUBBLE CAGE   1 UNIT   1 UNIT   1 UNIT   1 UNIT   1 UNIT   1 UNIT   1 UNIT
SUB-PINCH ROLLER (mm)   100 x 1000L   140 x 1500L   140 x 1700L   140 x 2100L   165 x 2800L   165 x 3300L   215 x 4200L
GUIDE MOTOR   20 kg/cm   30 kg/cm   50 kg/cm   50 kg/cm   50 kg/cm   50 kg/cm   75 kg/cm
WINDING UNIT TYPE   ONE STATION TYPE SURFACE WINDER
EFFECTIVE WIDTH   950 mm   1400 mm   1600 mm   2000 mm   2700 mm   3200 mm   5000 mm
DIA. OF FILM WOUND-UP ROLL   800 mm   800 mm   800 mm   800 mm   800 mm   800 mm   800 mm
WINDING MOTOR + INVERTER CONTROLLER   1 HP   2 HP   3 HP   3 HP   5 HP   5 HP   5 HP
SHIPPIING DATA(APPROX) DIMENSION (LxWxH)(M)   6.5 x 2.6 x 5   7.5 x 3.1 x 7   8.0 x 3.6 x 8   8.5 x 4.2 x 9   9.5 x 4.5 x 10   11 x 5 x 12   12 x 5.5 x 16
ANNEALLING DEVICE
Gravimetric Dosing Unit Oscillating Take Up Unit
IBC (Internal Bubble Cooing Computer Control System) Line Speed Synchronized with Computer Control
Thickness Measurement Two Stations Surface Winder
Thickness Controller Chiller
Automatic Hopper Loader Heat Slitting Device
Film Surface Treater EPC (Edge Position Control)
Pressure Gauge Electronic Tension Control
Rotary Die Crane for Die and Air Shaft
Automatic Gauge Control with
Automatic Cooling Ring 		PIB Pump System (For LDPE/LLDPE)

*Specifications are subject to change without notice for improvement.
MODEL:
KS-FLL55
KS-FLL65
KS-FLL75
KS-FLL85
KS-FLL100
KS-FLL120 Video
KS-FLL150 Video


KS-FLL55

KS-FLL65

KS-FLL65

KS-FLL75

LL/LLDPE HIGH SPEED BLOWN FILM LINE WITH GRAVIMETRIC BATCH BLENDER,
OSCILLATING TAKE-UP UNIT AND BACK TO BACK SURFACE WINDER.

KS-FLL120

KS-FLL150

LL/LLDPE HIGH SPEED BLOWN FILM LINE WITH GRAVIMETRIC BATCH BLENDER AND BIC,
HIGH EFFICIENCY FOR PE SHRINKABLE FILM, AGRICULTURAL & INDUSTRIAL FILM WITH
JOMBO GUSSETING DEVICE.
