MODEL
|
|
KS-FE45S
|
|
KS-FE50S
|
|
KS-FE55S
|
|
FEATURE
|
MATERIAL TO BE USED
|
|
HDPE
|
|
MAX.FILM WIDTH
|
350mm
|
|
450mm
|
|
550mm
|
|
THICKNESS OF FILM
|
0.008~0.08 m/m
|
|
MAX.EXTRUSION OUTPUT
|
75 kg/hr
|
|
90 kg/hr
|
|
135 kg/hr
|
|
EXTRUDER
|
SCREW DIA.
|
|
45 mm
|
|
50 mm
|
|
55 mm
|
|
SCREW L/D
|
30:1
|
|
30:1
|
|
30:1
|
|
SCREW/CYLINDER MATERIAL
|
SACM-645 STEEL WITH HARD WITH NITROGEN TREATMENT
|
|
CYLINDER COOLING
|
1/4,1/2 HPx1
|
|
1/4,1/2 HPx1
|
|
1/2 HPx3
|
|
DRIVING MOTOR
|
30 HP
|
|
40 HP
|
|
50 HP
|
|
HEATER CAPACITY
|
18 kw
|
|
20 kw
|
|
24 kw
|
|
DIES (mm)
|
60Ø x2
|
|
75Ø x2
|
|
100Ø x2
|
|
TEMPERATURE CONTROL
|
10 ZONES
|
|
10 ZONES
|
|
11 ZONES
|
|
COOLING EQUIP
|
2 HP x 2
|
|
2 HP x 2
|
|
3 HP x 2
|
|
TAKE-UP UNIT
|
TYPE
|
|
FIXED TYPE
|
|
PINCH ROLLER (mm)
|
165Øx400Lx2
|
|
165Øx500Lx2
|
|
165Øx600Lx2
|
|
TAKE-UP MOTOR
|
1/2 HP
|
|
1/2 HP
|
|
1 HP
|
|
TAKE-UP SPEED (m/min)
|
12~120
|
|
12~120
|
|
12~120
|
|
SUB-PINCH ROLLER (mm)
|
100Øx400Lx2
|
|
100Øx500Lx2
|
|
100Øx600Lx2
|
|
GUIDE MOTOR
|
10 kg/cmx2
|
|
15 kg/cmx2
|
|
15 kg/cmx2
|
|
WINDING UNIT
|
FW TYPE
|
|
ONE STATION AUTOMATIC SURFACE TYPE WINDER x 2
|
|
EFFECTIVE WIDTH
|
350 mm
|
|
450 mm
|
|
550 mm
|
|
DIA. OF FILM WOUND-UP ROLL
|
1000 mm
|
|
1000 mm
|
|
1000 mm
|
|
WINDER MOTOR
|
1 HPx2
|
|
1 HPx2
|
|
1 HPx2
|
|
DIMENSION (LxWxH)(M)
|
5.3x3.2x3.7
|
|
5.3x3.4X4
|
|
5.6x4.1x4.5
|
|
OPTIONAL DEVICE
|
|
Gravimetric Dosing Unit
|
Oscillating Take Up Unit
|
|
IBC (Internal Bubble Cooing Computer Control System)
|
Line Speed Synchronized with Computer Control
|
|
Thickness Measurement
|
Two Stations Surface Winder
|
|
Thickness Controller
|
Chiller
|
|
Automatic Hopper Loader
|
Heat Slitting Device
|
|
Film Surface Treater
|
EPC (Edge Position Control)
|
|
Pressure Gauge
|
Electronic Tension Control
|
|
Rotary Die
|
Crane for Die and Air Shaft
|
Automatic Gauge Control with
Automatic Cooling Ring
|
PIB Pump System (For LDPE/LLDPE)
|
|
*Specifications are subject to change without notice for improvement.
